BRUVAL® is a manufacturer of high-pressure pipeline equipment and specializes in producing both customized and standard equipment for pipeline installations.

Welding WorkerQuality AssuranceBypass Pipeline txtCutterPilot DrillFlow StoppingHigh Pressure Gate ValveSplit Tee FittingHoling MachineFlowStopper Machine

Download our full technical documentation on the selected product

Download

BRUVAL® High-Pressure Gate Valves

Our standard and customised High-Pressure Gate Valves, compatible with the market high-pressure pipeline equipment, are designed and manufactured by BRUVAL® highly qualified engineers and can be used with the BRUVAL® Fittings, Holing, and FlowStopper Machines in order to meet our customers’ specific needs.

Our High-Pressure Gate Valves are intended to be used with pipelines from 12 up to 68 inches, supplied to match ASME Class from 150 to 1500. They are available for operating pressures of up to 250 bar, and can be operated either manually or hydraulically. The valves are bidirectional, and thus can function in parallel or perpendicular orientation.

In comparison with conventional valves, the new generation of BRUVAL® High-Pressure Gate Valves requires less frequent maintenance, and has a significantly increased lifetime due to a 70% reduction of wear and internal stresses. Our valves significantly reduce the risk of leaks and, due to their design, they are much more convenient in terms of weight and size. All our valves include positive shut-off, integral flange studs, an oversized bore, and a built-in pressure equalizing valve.

We invite you to contact us for further information about the different products we provide, fulfilling your specific pipeline needs and requirements.

MAKE A REQUEST

BRUVAL® FlowStopper Machines

BRUVAL® hydraulically operated FlowStopper Machines can be customised to the special needs of each operation. Our FlowStopper Machines are available for pipeline internal nominal diameter (INT.DN) from 12 inches up to 68 inches and under an operating pressure of up to 250 bar at 60°C. The maximum operating temperature of our FlowStopper Machines is 110°C.

We invite you to contact us for further information about the different products we provide, fulfilling your specific pipeline needs and requirements.

MAKE A REQUEST

BRUVAL® Holing Machines

BRUVAL® offers hydraulically operated Holing Machines for various materials, such as steel, cast iron, stainless steel, cement, carbon, copper, brass, and polyethylene, with an internal nominal diameter (INT.ND) from 12 up to 68 inches, and under an operating pressure of up to 250 bar at 60°C without interruption of flow. Our Holing Machines maximum operating temperature is 110°C.

We provide a new generation of interchangeable cutting inserts, adaptable to the temperature and pressure requirements of specific pipe operations. Additionally, we offer equipment that can be customised for the special needs of each operation. These technologies can be used in the preparation stage for FlowStopper Machine operations. In compliance with our environmental policy, we ensure no pipe content is released to the atmosphere during drilling operations performed with our machines.

We invite you to contact us for further information about the different products we provide, fulfilling your specific pipeline needs and requirements.

MAKE A REQUEST
fittings_booklet_Perspective
Split Tee

Split Tee

Multidirectional Tee

Multidirectional Tee

Nozzle

Nozzle

Multidirectional Nozzle

Multidirectional Nozzle

Sleeve

Sleeve

BRUVAL® Fittings

BRUVAL® provides a wide variety of standard and customised fittings from 12 to 68 inches, engineered to complement our Holing and FlowStopper Machines. Our fittings are also compatible with the market-standard pipeline equipment. We manufacture Split or Multidirectional Tees, Nozzles or Multidirectional Nozzles, and Sleeves matching ASME Class from 150 to 1500 and available for operating pressures up to 250 bar. Our fitting weldings are 100% radiographically and ultrasonically inspected.

We invite you to contact us for further information about the different products we provide, fulfilling your specific pipeline needs and requirements.

MAKE A REQUEST

BRUVAL® Flanges and Lock Discs

BRUVAL® provides high-pressure standard and customised Blank Flanges and Blind Flanges up to ASME Class 1500, from 12 to 68 inches, which are available for pressures of up to 250 bar. Our Flanges are available in all steel metal grades.

BRUVAL® offers high-pressure standard and customised Lock Discs, withstanding operating pressures of up to 250 bar, for pipe diameters from 12 up to 68 inches, and with ASME Class from 150 to 1500 flanges.
